JamieDaugherty

Out of the box, Ohlins shocks need some work to perform best. They are mass produced just like the OEM Showa units - and suffer because of it. For sure they perform better than the OEM shock, but do not be fooled into thinking you are buying the best - in fact that is far from the truth. If you consider an Ohlins probably best to consider sending it off to get the correct spring rate and valving package installed. FYI!

AHHHHHHH! No I didn't! Everything I install is my own valving, I don't like to help out my competition! As for an upgraded rebound, that only really helps the very aggressive or track riders. New shim stacks on the stock rebound valves is plenty for most riders. The trick is getting the correct shim stack setup, but that's where experience comes into play.

I wish it was that easy! In the end I've found that I can make custom triples to the precise dimensions I want for about the same price. It pays to have suppliers that you've developed a good relationship with!

I do not suggest using an extended upper mount to make up that much distance. You would be running a serious risk of failure. All of the 929 shocks that I build are converted so they fit without any changes to the upper mount - FYI

eMachineshop = VERY expensive. Try a local machine shop and I think you will be able to cut the price in half. I've used 3D printed parts on some of my motorcycle products. They work really well. The printed ABS parts are 70-80% as strong as their injection molded counterparts. That said, there isn't very many applications for what I do that a plastic part is appropriate. The printed parts are good for making physical prototypes just to check that everything works the way I want it to do. I have a bunch of these sitting on the shelf - at least they look pretty! All of that said, I have found that having parts CNC machined from aluminum and paying for the 1-2 qty piece price is about the same as a 3D printed plastic part. So, for the same $$$ you can have a real functional part. I have found 3D printed parts work best when the final result is a complicated piece that would take fixturing to machine.

I'm talking from merely a higher rated spring than the VFR point of view. Not everyone has nearly $400 to throw at the suspension, and you can pick up a XX shock for less than $50. If you HAD to go cheap on the quick, it is a viable option for people over 200 lbs. This is true, but it is still WAY low for the VFR. The spring on a CBR1100XX shock is good for a 65lb rider, so if my 10 year old daughter was riding the bike it would be ok. Same goes here too. The stock spring on the CBR929 shock is the same as the VFR800, the problem is an ideal rider for that spring is 12lb. None of my kids are that small anymore so I won't even make a correlation for that!

You might as well upgrade the standard shock, and then get a better spring, tailored to your weight. Just getting the XX shock will do little, but it might be a small step up from the standard VFR shock. The CBR1100XX is no better than the VFR800. Nothing to be had there!

I keep plenty of them in stock, not a problem!

I've been doing that for about three years now. The F4 is required for ABS models but either the F4 or a 929 is an option for non-ABS 6th Gen bikes.

Those covers look great! What a neat idea.

Here are the tables for a VFR800 Forks: 110-145lb 0.85kg/mm 145-175lb 0.90kg/mm 175-210lb 0.95kg/mm 210-245lb 1.00kg/mm 245-280lb 1.05kg/mm Shock 110-145lb 1050lb/in 145-175lb 1100lb/in 175-210lb 1150lb/in 210-245lb 1200lb/in 245-280lb 1250lb/in I would certainly suggest a set of 0.95kg/mm springs up front and a 1150lb/in (20.54kg/mm) spring out back. This would apploy to all street riders, the only time you would need to change is if you were an expert track rider on slicks. I hope this helps!

The CBR-XX is the same length as the 02+ VFR800 shock - FYI

I've found that mounting the reservoir on the right hand side does not require any modifications to the battery box. As you have shown, it can be done either way. it's always nice to have flexibility! Bear in mind the CBR-XX shock is no better than the VFR800 stock unit, so no advantage to changing to it.

Springs rate is independent of fluid height. Fluid level is directly related to fork travel.

Actually, the spring rate plays no part in this discussion. Fluid level creates the available volume for the air to compress when the forks travel. Without enough air gap in the forks the air pressure will ramp to an excessive level. This causes a variety of problems. Not only can this lead to premature seal wear but there are performance drawbacks as well. The air "spring" inside the forks ramps up at an exponential rate, with too much ramp up the effective travel of the forks will be reduced. The VFR's have approximately 109mm of fork travel, the commonly accepted "good" number is more like 120mm. Since the VFR's are already starting out behind the 8-ball in the fork travel department it's best to not reduce it any further.

100mm is far too much fluid. For the VFR800's I suggest 130mm, but never go beyond 120mm. Any more fluid and your internal air pressure ramps to the moon before full travel is reached. Each bike/model/generation is different and this information applies to VFR800's only (both Ø41mm and Ø43mm forks).

Heat on the reservoir is not a problem. The shock itself generates more heat than it would get from the engine. Don't worry - it's designed for that kind of environment. With good quality fluid it will be just fine.

We would like ALL the info on this install as you are the first to get a 929 shock to fit a Vtec w/o more mods. Please tell us exactly what and how you did it, where was the spacer installed? Top or bottom, what way was the reservoir facing? front or rear, is it hitting the head or tray? etc., etc. There are several members trying to get their 929 shock to fit w/o any luck. Thanks BR This is not a true statement. I have built MANY of these and they were installed without a problem. The 6th Gens are tight but it can be done without modifcation. Not sure why you are trying to discourage other forum members but this is a very viable performance upgrade for non-ABS 02+ bikes.

Try checking out hondavfr.org . There is lots of details in FAQ section. For those not wanting to cut/weld the rear caliper bracket I'm planning to come out with a plug-n-play Machined bracket later this coming spring (hopefully). I'm also hoping to get a it together for use with the stock forks too. I think the above mentioned site should give you a lot of details, at least enough to get you started.

Very nice!
