  1. cargustav, great detective work with the pressurizing mechanism and bubble factory. I sincerely apologize that you are having to wrestle with these problems. I’ll ask Wade about the leaking at several places on your headers. A friend of mine is the owner of a local automobile exhaust shop, motorcyclist, and long ago built headers for a VF500. Side note: a year or so ago, I approached him about building our headers, but he declined. He uses the copper silicon in the photo below on all slip joints and potential exhaust leak spots. I’ve got to get my bike back together and check my production headers for leaks.
  2. I’m late to the party, but this thread is probably the best example I’ve ever seen of our community in action. It’s like carlgustav has more than 6-7 experienced guys in his garage w him, and they can instantly run out to their own bikes to check stuff, then return to his garage. I don’t have much to add regarding fueling - I take good care of my bike, but still feel luckier every day that my 2001 w 60k miles just runs and runs. I can offer a bit of supporting evidence about possible leaks from Delk 42mm crush gaskets. When I’ve installed the new headers w Delk 42mm gaskets (seam side toward the head), they’ve always resulted in a crush and seal like the one in the photo below (photo is of a 5 gen) so I never kept close track of which gasket did what on which cylinder. It’s visible that the gasket seated further from the port at the lower right of the photo - that’s the part of the gasket that was last to go into place and really really didn’t want to go there without a fight. One thing that was clear was that the Delk 42mm gaskets are a bitch to get started on a 5 gen - on about 30% of 5 gen cylinders I had to let the headers do the final insertion. On the one 6 gen and one 8 gen where I’ve used them, the gaskets went into place with only a little wrestling and fewer curse words.
  3. Thanks Buzzner. Sounds dodgy - glad you were able to nurse it home. My issue must be something else, probably one last air bubble I don’t know how to find/get rid of.
  4. Buzzner, what behavior does a master cylinder with a plugged return port exhibit? I’ve been chasing a soft-levered 5 gen delinked front brake system for ages, bled the system carefully multiple times, rebuilt master and calipers w OEM Honda parts, but didn’t know about a return port or how to check it.
  5. Thanks for doing the legwork to find Prismatic's Triple Bronze as a match for 8 gen accent colors. Did you try Triple Bronze out on a test piece before having all those parts coated?
  6. Hi eyrwbvfr - I've recently changed my subjective preference from new headers with no bungs and PC3 on a 2000-2001 VFR to one bung in the collector exit and PC3. I changed my mind when Jozef - the dyno tech at Attack Performance - was pleased to find an 18mm bung in the collector exit of the 8 gen test headers. He gets more accurate readings from his Bosch wide band sensor inserted into a bung in the collector exit than he does with a 'sniffer' inserted down the tailpipe. A number of VFRD and VFRW members with 2000-2001s are getting good results with PC3, and some are happy with Rapid Bike fuel management systems. You may have read other posts in this thread that document the problems the 2000-2001s have with PCV - stay away from that device. An option would be to plan on headers with one bung for dyno tuning and obtain Dynojet O2 Optimizers to plug into your VFR's wire harness where the O2 sensors used to connect. There is a dyno chart earlier in this thread that has three graphs that pertain to your question: one graph line for baseline stock 5 gen, one with the headers installed but a zero map on the PC3 [zero map means the PC3 makes no changes to OEM fueling], and the third graph on the chart representing the headers with a custom tune done on the PC3. The timing for the next production run of 5/6 gen headers depends on when we gather an order for 15 units or more. A rough estimate for delivery of the next group of 5/6 gen headers is 10 weeks from now.
  7. Thanks for the generous offer, Dennis. We were able to put together a 6 gen slipon muffler assembly and test the headers with it. I bet your pipes sound better, though.
  8. Man, the folks on this forum come up with some of the coolest ideas! carlgustav, that perf metal is brilliant for prototyping - bends as easy as cardboard, but stays bent.
  9. Thanks! It's super cool of you to consider loaning us a set of pipes as nice as your Leos. We did manage to get the 6 gen onto the dyno, and the associated muffler project was a trip which will be detailed in a separate thread soon.
  10. Here are a few notes spawned by MooseMoose's awesome, informative, and more than a little amusing installation thread. If you purchased headers, or think you might, or think you might ever install a set of any headers in your life, you can find MooseMoose's thread here: And this is a bit of extension/extrapolation on his findings: +1, +2, +3 on all the compliments for MooseMoose's detailed documentation of his header install odyssey! Great work, and thanks to him for all the extra time he put into sharing so much pertinent information with the community. Here are a couple observations/additions that occurred while reading his thread: - Header stud nuts, torque, and anti-seize Confirmed: 9ft-lbs is more than enough to hold things together ESPECIALLY if using anti-seize. I bent flanges on the prototype headers when I used anti-seize and torqued the nuts to 9 ft-lbs. I suspect that at 9ft-lbs, the lubrication component of the anti-seize allows greater force to be exerted than 9ft-lbs on 'dry' threads with no anti-seize. I have chosen to wipe the anti-seize from the studs' threads on the 4 VFRs I've been using for the header project. I say 'wipe off' because I just remove what will come off with a rag and do not clean with any cleaner or solvent. Who knows, there might be enough residual a-seize left to do just enough good. CAUTION 6 GEN OWNERS: in the list of torque values on page 2-3 of the 6 gen service manual, Honda states 'exhaust pipe flange nut' 15 ft-lbs. This is NOT the nut NOR the torque value of the header stud nuts we use to hold our headers to our heads. That sounded weird, but this problem with Japanese-to-English translation has caused one owner of new headers to overtorque the header stud nuts. Thankfully, no damage occurred. Honda calls the header stud nuts 'Special Nuts', which sounds like a breakfast cereal one would eat while listening to MooseMoose's fictional band 'Overtorqued Nuts'. [Actually Honda calls them 'exhaust pipe joint special nuts' and specifies their torque value at the aforementioned 9ft-lbs] Later in section 2 of the 6 gen manual the exhaust component torque values shown on the drawings are correct. Be patient with the special nuts. As MooseMoose suggests, make circuits around all the nuts starting when they are all just finger tight. I've had 9-10 shots at removing and installing headers recently, and this procedure works best for me: Once all 8 nuts are finger tight using a socket on extensions but no wrench, go through all 8 nuts in a circuit around the bike, adding 1/2 turn of tension. This takes a fair amount of time, but keeps all the exhaust components gently easing together into their happiest states. As soon as a 1/2 turn begins to require more tension - this will happen on one or two nuts before it happens on the others - switch to the torque wrench and set it at 5 ft-lbs. Go around another circuit of all 8 nuts, adding another 1/2 turn only where necessary until all 8 nuts reach 5 ft-lbs. Change the torque wrench setting to 6 ft-lbs and go around again, taking each nut up to 6 ft-lbs. Change the wrench's setting to 7 ft-lbs, rinse and repeat. On both 5 gen test bikes, going from 7 ft-lbs to 8 ft-lbs required only a tiny bit of wrench rotation, and going from 8 ft-lbs to 9 didn't produce any movement at all - I believe this is because the nuts were tight enough at 8 ft-lbs, and probably would have been safely secure at 7 ft-lbs. On the 8 gen test bike, the nuts stopped moving at 8 ft-lbs instead of 7 ft-lbs. Wade laughs at me when I crawl around the perimeter of a VFR with a torque wrench, carefully setting each nut. He says "Just tighten 'em until they stop crushing the gasket!". I guess with as much experience as he has, he can confidently 'feel' when the gasket stops crushing. I've chosen to stay with the torque wrench...it is my friend.
  11. Yep, that's originally why I wanted to coat them. Vanity. Pure vanity. And that is the rub - a question that was brought up is "How does a professional applicator effectively coat the insides of multiple, connected bendy tubes?" Answer: A coating company Duc2V4 told me about [Thank you Duc2V4] has devised a simple method of coating the inside of headers. This is so simple and of such quality that at first I thought the idea must have come from Mohawk. They plug the ends of the headers and pour the tubes full of the same ceramic coating that they apply to the tops of pistons, then they pour out the excess material before curing the headers. And yes, standard ceramic coating on the outside of headers is thin...so thin that it is described as mechanically delicate [scratches easily]. The coating place also explained that different colors of the same ceramic coating product have different mechanical strengths - silver is toughest and most scratch resistant, black is weakest and scratches easiest, titanium [the color, not the metal] is somewhere in between, but closer to silver in strength.
  12. Hey Nick - sounds good. Sorry to have taken so long to reply - I've been neglectful due to needing to get caught up with the day job and real life. A few guys have placed deposits on 5/6 gen headers for the 3rd production run, so that will be the next undertaking after the 8 gens get finished.
  13. 6 gen headers have had 5/8" cut off the collector exit, so it may very well be possible to slip the headers on over an installed center stand. The three-point fastening of the 6 gen muffler system won't fit correctly with the stock 5 gen collector length. If you've ever wrestled a set of 6 gen mufflers onto a set of 98/99 OEM headers, you know exactly what I'm describing.
  14. +1, +2, +3 on all the compliments for MooseMoose's detailed documentation of his header install odyssey! Great work, and thanks to him for all the extra time he put into sharing so much pertinent information with the community. Here are a couple observations/additions that occurred while reading this thread: - Header stud nuts, torque, and anti-seize Confirmed - 9ft-lbs is more than enough to hold things together ESPECIALLY if using anti-seize. I bent flanges on the prototype headers when I used anti-seize and torqued the nuts to 9 ft-lbs. I suspect that at 9ft-lbs, the lubrication component of the anti-seize allows greater force to be exerted than 9ft-lbs on 'dry' threads with no anti-seize. I have chosen to wipe the anti-seize from the studs' threads on the 4 VFRs I've been using for the header project. I say 'wipe off' because I just remove what will come off with a rag and do not clean with any cleaner or solvent. CAUTION 6 GEN OWNERS: in the list of torque values on page 2-3 of the 6 gen service manual, Honda states 'exhaust pipe flange nut' 15 ft-lbs. This is NOT the nut NOR the torque value of the header stud nuts we use to hold our headers to our heads. That sounded weird, but this problem with Japanese-to-English translation has caused one owner of new headers to overtorque the header stud nuts. Thankfully, no damage occurred. Honda calls the header stud nuts 'Special Nuts', which sounds like a breakfast cereal one would eat while listening to MooseMoose's fictional band 'Overtorqued Nuts'. [Actually Honda calls them 'exhaust pipe joint special nuts' and specifies their torque value at the aforementioned 9ft-lbs] Later in section 2 of the 6 gen manual the exhaust component torque values shown on the drawings are correct. Be patient with the special nuts. As MooseMoose suggests, make circuits around all the nuts starting when they are all just finger tight. I've had 9-10 shots at removing and installing headers recently, and this procedure works best for me: Once all 8 nuts are finger tight using a socket on extensions but no wrench, go through all 8 nuts in a circuit around the bike, adding 1/2 turn of tension. This takes a fair amount of time, but keeps all the exhaust components gently easing together into their happiest states. As soon as a 1/2 turn begins to require more tension - this will happen on one or two nuts before it happens on the others - switch to the torque wrench and set it at 5 ft-lbs. Go around another circuit of all 8 nuts, adding another 1/2 turn only where necessary until all 8 nuts reach 5 ft-lbs. Change the torque wrench setting to 6 ft-lbs and go around again, taking each nut up to 6 ft-lbs. Change the wrench's setting to 7 ft-lbs, rinse and repeat. On both 5 gen test bikes, going from 7 ft-lbs to 8 ft-lbs required only a tiny bit of wrench rotation, and going from 8 ft-lbs to 9 didn't produce any movement at all - I believe this is because the nuts were tight enough at 8 ft-lbs, and probably would have been safely secure at 7 ft-lbs. On the 8 gen test bike, the nuts stopped moving at 8 ft-lbs instead of 7 ft-lbs. Wade laughs at me when I crawl around the perimeter of a VFR with a torque wrench, carefully setting each nut. He says "Just tighten 'em until they stop crushing the gasket!". I guess with as much experience as he has, he can confidently 'feel' when the gasket stops crushing. I've chosen to stay with the torque wrench...it is my friend.
  15. Best, simplest idea yet. And it wouldn't have to hang a single thing on the 6 gen midpipe. 5 GEN RIGHT SIDE CENTER STAND BOLT IS REGULAR RIGHT HAND THREAD HighSideNZ - you are correct about 6 gen 8 GEN RIGHT SIDE CENTER STAND BOLT IS REVERSE LEFT HAND THREAD [Recent experience with dyno test bike]
×
×
