Howdy All,
For anyone who might be curious of the results, I performed a first ever valve clearance check on my 04 with 96,864 miles on the clock. I wasn't having any known issues, fact to me, the bike was running just fine. I did the check mostly out of curiosity.
Six were out of spec. Two were near the limits and were re shimmed. Red = out of spec
Between the shims, gaskets and a few other items I've got about $350 bucks into the job, not sure how many hours (lots).
Cylinder #1
IN – N IN – Vtec
0.20 0.20
EX – N EX – Vtec
0.35 0.35
Cylinder #2
IN – N IN – Vtec
0.15 0.15
EX – N EX – Vtec
0.28 0.28 (Vtec side 0.28 just within spec – decided to re shim)
Cylinder #3
IN – N IN – Vtec
0.20 0.20
EX – N EX – Vtec
0.33 0.23 (normal side 0.33 just within spec, decided to re shim)
Cylinder #4
IN – N IN – Vtec
0.10 0.18
EX – N EX – Vtec
0.23 0.20
