FairWeatherFellow

Nothing was said about the man personally, I have spoke with him quite a bit about the issues I've been having and he's been very responsive to what has happened. We set up returns and came to agreements with what happened yes. The stator was operating properly, the battery passed the load test, and the new RR I had installed failed in no time at all. The vfrness had .04 ohms of resistance as well as one wire that was corroded through and through. Not to mention the plug to the RR had failed and I had to use the factory plug because he didn't have anymore. As soon as I removed the products from wiremybike my nightmare stopped immediately. I'm saying this to keep others from going through the same thing I did. Just input from a consumers standpoint. If I'm going to be honest I can't just say good things, because good things didn't happen. This cost me hundreds and hundreds of dollars in town bills and parts, not to mention lots of upsetting moments. Sorry to bad mouth someone but that's how it is. Miles

Ok, so a little update here. I deduced that the Rick's Electronics RR was bad, also the VFRNess had a little above normal resistance from plug to plug. The Rick's Electronics stator functioned properly though, giving a solid current output cold and hot so i just left it in. I purchased the FH020AA from roadstercycle.com in hopes that it would function properly. I removed the VFRNess and salvaged the 3 yellow stator wires and connector, one of the wires had corrosion through and though. I cleaned up the contacts ends and used it. So wired it straight from the stator to the RR and straight from the RR to the battery (same set-up and the VFRNess) i kept the jump wire from the battery to the starter relay via the fuse block supplied by roadstercycle.com. So far it works flawlessly, the battery is at 14.4 constant while the bike is running. There isn't any real variation from revving or idle and is very consistent, and the voltage did not drop once the bike got hot!! Due to the larger unit i couldn't use the factory subframe mount and keep my passenger pegs, so i suspension mounted it in the opening next to the battery box. Should help to keep is cool (even though the unit really didn't heat up at all). I will report back if i encounter further issues. To sum it up DON'T USE PRODUCTS FROM wiremybike.com it effed everything up and they all failed. Thanks for the input guys! Miles

I really need to do a voltage meter, unfortunately at this stage it will just tell me what I already know. Charges cold, stops charging when it gets hot regardless of new, old, used, OE or aftermarket parts that are on it. I thought I was getting the 800fi RR with the new connector but it turned out to be an Aftermarket unit after all. I'll look for one

Where would I go to find a new OEM stator in this day and age? After calling every dealer in the State and searching every inch of the web I have only found OE replicas. Which is Rick's electronics recommend by wiremybike.com who lots of these guys on here swear by that stuff. The stator I pulled out of the bike looked fine really, wasn't black and nasty or anything. Battery is a couple of weeks old, besides it dying a couple of times I've kept up on it just fine. Ditch the stator connector, what do you mean by that? Miles

Ok so if not really sure what's up with my luck, but it's pretty bad. I'll give you the run down in the order it all happened. Had electrical problems when I first got the bike, flickering lights, and generally bad behavior. So I replaced the RR with a "OE" I got off eBay and put in the vfrness, problem solved. I took the bike to the track, RR caught fire and took the vfrness plug with it. I replaced the plug and RR with Rick's electrical RR. Problem solved. Couple of weeks later the battery just keeps dying on me over and over and it just can't seem to hold a charge, figure the RR nightmare may have cooked the battery. So I replace it, Problem not solved. So I look around and find the pins in the RR plug are loose so I mess with them but the plug is trash so I replace it. Still doesn't fix it. The bike will charge cold, but once it gets hot it stops charging. Heat soaked stator, replaced that bitch. Seemed to be charging fine so I went for a ride, 10 miles in I have a dead battery. Seconds before rolling my bike off a cliff I decided to throw on the OE RR i originally took off the bike for shits and giggles. Jump started it, rode it home, battery at 12.9 volts, problem solved. 50 miles later, I have a dead battery once again. Are both the RRs I have toast? Am I being haunted by some electrical phantom, should I try another new RR? At this point I'm ready to just give it to some kid walking down the street... Thanks for listening, if you have any advice I'll take it. Miles

Welp luckily it wasn't anything catastrophic or a pain to deal with. When I went to check the current on the plug coming from the stator, I noticed the metal pins inside my plug had slid back out of place and not making a connection. A little upsetting that when I went to shove them back in place they didn't snap in. I had the bend the back of the tangs up and front down. Oh well, easy fix, but poor quality on the plug part. Thanks for the suggestions gentlemen.

Alright I'll give it a shot, I've got a few manuals here I'll reference for AC. Could having one of the yellow wires mixed up at the plug cause an issue? I assume it's the same signal from each right? Thanks, Miles

I think it looks best from this angle IMO ?. The Ridge Motorsports Park Shelton, WA

So i thought I solved my electrical issues with the VFRNESS and new RR. Last RR was junk and caught on fire, replaced it with a RR from wiremybike.com. After I spliced in the new plug and put in the new RR my battery started dying on me. It would take a charge but wouldn't keep it, got it load tested and came up bad, so I replaced it. Now with the new battery I have zero volts coming back to the battery from the bike. Think it's the stator? How can I test it? Thanks, Miles

Great info, thanks man. Actually had the slave go out that I replaced my old one with, just stopped holding pressure and puked it's guts out everywhere. Now the original is on and works great. Miles

Rectumfrier sounds about right! Well all the parts are on their way and she should be up and running by the end of the week! Hopefully with a quality RR replacement this won't ever happen again...

Yeah no shit! Was probably the best place it could have happened, if I was on the side of the road it could have taken my whole bike down with it... Just have some fairing repair to do and the seat is fairly unscathed for what happened, I have a new cover I'm going to throw on it. Ordered a new type reg/rec from wiremybike.com along with a new plug for the VFRNESS. The reg/rec that was on there was an aftermarket "replacement" never again, learned my lesson the hard way. The irony in this is that I had the spare OE reg/rec in my backpack too just in case.... didn't think it would go out like that though. Thanks guys! Miles

So this weekend I was down in Shelton, WA at The Ridge Motorsports track flagging and doing some track time. I rode down that morning (130 miles) with no problems. Also I've had my Reg and the VFRNESS installed for about 3k miles without any issues. The only thing I ever noticed is my lights would get brighter at 9-11k RPM's. Anyways I was able to ride the track for 20 minutes, about 8 hot laps of pure V4 glory with no issues. Parked for a brief 5-10 minute lunch before I hopped back on the track for about a mile to get back to my post at turn 8. When I got off the bike I noticed a little smoke from the rear wheel area, first I thought maybe hot header? Or some smoke from the tires? It was probably 85+ with real hot pavement. I walked around the other side and saw flames erupting from my f***ing fairings!! Luckily I had a fire extinguisher at my post and blasted away at it to no avail, had to rip off my side fairing and unplug the damn thing. Very sad way to end an awesome day ?
